Router xpon inalámbrico n 300 con catv | tp-link | xn021-g3 | 1 puerto gpon sc/apc | 1 puertos lan ge y 1 puerto lan fe | 1 puerto catv | soporta aginet config- aginet acs

CARACTERÍSTICAS DE HARDWARE

INTERFACE: 1× 10/100/1000 MBPS RJ45 LAN PORT
1× 10/100 MBPS RJ45 LAN PORT
1× CATV PORT
1× PON PORT
BOTÓN: RESET BUTTON
FUENTE DE ALIMENTACIÓN EXTERNA: 9V/0.6A
VELOCIDAD DE DATOS: DOWNSTREAM SPEEDS: 2.488 GBPS (GPON), 1.25 GBPS (EPON)
UPSTREAM SPEEDS: 1.244 GBPS (GPON), 1.25 GBPS (EPON)§
ANTENA: 2× EXTERNAL ANTENNAS


CARACTERÍSTICAS INALÁMBRICAS

ESTÁNDARES INALÁMBRICOS: IEEE 802.11B/G/N 2.4 GHZ
FRECUENCIA: 2.4 GHZ
TASA DE SEÑAL: UP TO 300 MBPS
FUNCIONES INALÁMBRICAS: ENABLE/DISABLE WIRELESS RADIO, WMM, WIRELESS STATISTICS
SEGURIDAD INALÁMBRICA: WPA/WPA2/WPA3 ENCRYPTIONS
POTENCIA DE TRANSMISIÓN:
CE:
20 DBM
CALENDARIZAR INALÁMBRICAMENTE: SUPPORT 2.4 GHZ WIRELESS SCHEDULE

CARACTERÍSTICAS DE SOFTWARE


CALIDAD DE SERVICIO: WMM
CARACTERÍSTICAS AVANZADAS: PARENTAL CONTROLS, NETWORK ADDRESS TRANSLATION(NAT), PORT MAPPING(GROUPING), STATIC ROUTING, DNS RELAY, DDNS,
IPTV SUPPORT, IGMP V2/3 AND IGMP SNOOPING/PROXY
SEGURIDAD: SPI FIREWALL, DDOS, ACCESS CONTROL, IP-MAC BINDING
ADMINISTRACIÓN: LOCAL MANAGEMENT: WEBGUI MANAGEMENT
REMOTE MANAGEMENT: OMCI, TR-069, TR-098, TR-143
DHCP: SERVER, CLIENT, DHCP CLIENT LIST, ADDRESS RESERVATION, DHCP RELAY
PORT FORWARDING: VIRTUAL SERVER, PORT TRIGGERING, DMZ, ALG, UPNP
DYNAMIC DNS: DYNDNS, NO-IP
PROTOCOLOS: IPV4, IPV6

OTROS


CONTENIDOS DEL PAQUETE: 1× XPON ROUTER XN021-G3
1× RJ45 ETHERNET CABLE
1× POWER ADAPTER
1× QUICK INSTALLATION GUIDE
REQUISITOS DEL SISTEMA: MICROSOFT WINDOWS 98SE/NT/2000/XP/VISTA™/7/8/8.1/10, MAC OS, NETWARE, UNIX OR LINUX
INTERNET EXPLORER 11, FIREFOX 12.0, CHROME 20.0, SAFARI 4.0, OR OTHER JAVA-ENABLED BROWSER
SUBSCRIPTION WITH AN INTERNET SERVICE PROVIDER (FOR INTERNET ACCESS)
AMBIENTE: OPERATING TEMPERATURE: 0 AND #8451;–40 AND #8451; (32 AND #8457;–104 AND #8457;)
STORAGE TEMPERATURE: -40 AND #8451;–60 AND #8451; (-40 AND #8457;–140 AND #8457;)
OPERATING HUMIDITY: 10%–90% NON-CONDENSING
STORAGE HUMIDITY: 5%–90% NON-CONDENSING
