Pantalla interactiva de colaboracion inteligente huawei ideahub b3 de 65 pulgadas, ihb3-65sa

PARAMETER NAME CONTENT
SYSTEM
CPU 8 CORES
MEMORY 8 GB
STORAGE SPACE 64 GB
AI COMPUTING POWER 4T+2T
OPERATING SYSTEM HARMONYOS IS SUPPORTED. THE OPTIONAL OPS SUPPORTS WINDOWS 10.
SCREEN DISPLAY
BACKLIGHT TYPE D-LED
ASPECT RATIO 16:9
RESOLUTION 3840 X 2160
DISPLAY AREA
• 65-INCH MODEL: 1428.48 MM X 803.52 MM
• 75-INCH MODEL: 1649.66 MM X 927.94 MM
• 86-INCH MODEL: 1895.04 MM X 1065.96 MM
PIXEL DISTANCE
• 65-INCH MODEL: 372.0 AND #956;M X 372.0 AND #956;M
• 75-INCH MODEL: 429.6 AND #956;M X 429.6 AND #956;M
• 86-INCH MODEL: 493.5 AND #956;M X 493.5 AND #956;M
REFRESH RATE 60 HZ
RESPONSE TIME 8 MS
BRIGHTNESS (TYPICAL VALUE) 350 NITS
SCREEN BRIGHTNESS UNIFORMITY AND #8805; 70%
CONTRAST 1200:1
VIEWING ANGLE AND #8805; 178°
COLOR DEPTH 10 BITS (8 BITS + FRC)
HARDWARE-BASED ANTI-BLUE LIGHT SUPPORTED
GLASS SURFACE TREATMENT ANTI-GLARE
SCREEN LAMINATION ZERO-GAP BONDING
GLASS SURFACE HARDNESS AND #8805; 7H
SCREEN TOUCH CONTROL
TOUCH CONTROL PRECISION ±1 MM
MAXIMUM NUMBER OF TOUCH POINTS 20
TOUCH CONTROL TYPE INFRARED TOUCH CONTROL
TOUCH RESPONSE TIME AND #8804; 10 MS
AUTOMATIC SCREEN BRIGHTNESS ADJUSTMENT SUPPORTED
CAMERA
LENS TYPE FIXED FOCAL LENGTH
SENSOR SIZE 1/2.8
HORIZONTAL FIELD OF VIEW 80°
APERTURE F1.8
VIDEO RESOLUTION 4K30 (3840 X 2160)
ZOOM 2X DIGITAL
VERTICAL ANGLE OF VIEW 50°
TV DISTORTION 2%
SHOOTING DISTANCE 0.5 M TO INFINITY
PTZ ADJUSTMENT E-PTZ
AUTOMATIC EXPOSURE (AE) SUPPORTED
AUTOMATIC WHITE BALANCE (AWB) SUPPORTED
LOCAL CAMERA PRESETS 30
BUILT-IN MICROPHONE
QUANTITY 6
SAMPLING FREQUENCY 48 KHZ
SAMPLING BITS 24 BITS
SOUND PICKUP ANGLE 180°
BUILT-IN SPEAKER
QUANTITY 2 X (HIGH-FREQUENCY SPEAKER + FULL-FREQUENCY SPEAKER)
TOTAL SPEAKER POWER 2 X 15 W
SOUND OUTPUT MODE FRONT TWEETERS AND BOTTOM FULL-FREQUENCY SPEAKERS
FREQUENCY RESPONSE RANGE 100 HZ TO 20 KHZ
STEREO SUPPORTED
MAXIMUM SOUND LEVEL 95 DB SPL@1 M
ELECTRICITY SUPPLY REQUIREMENTS
RATED OPERATING VOLTAGE 100–240 V AC
OPERATING FREQUENCY 50 HZ/60 HZ
MAXIMUM POWER CONSUMPTION
• 65-INCH MODEL: 350 W
• 75-INCH MODEL: 420 W
• 86-INCH MODEL: 450 W
TYPICAL POWER (WITHOUT OPS; BRIGHTNESS OF 300 NITS)
• 65-INCH MODEL: 141 W
• 75-INCH MODEL: 177 W
• 86-INCH MODEL: 208 W
STANDBY POWER 0.5 W
ENVIRONMENTAL REQUIREMENTS (IN USE)
AMBIENT TEMPERATURE 0°C TO +40°C
RELATIVE HUMIDITY 10% TO 95%
OPERATING ALTITUDE AND #8804; 5000 M
ENVIRONMENTAL REQUIREMENTS (IDLE)
AMBIENT TEMPERATURE –20ºC TO +60ºC
RELATIVE HUMIDITY (NON-CONDENSING) 5% TO 95%
PHYSICAL PARAMETERS OF THE ENTIRE SYSTEM
PRODUCT DIMENSIONS
• 65-INCH MODEL: 916.1 MM X 1484.5 MM X 91.6 MM
• 75-INCH MODEL: 1040.5 MM X 1705.7 MM X 91.8 MM
• 86-INCH MODEL: 1180.6 MM X 1953.0 MM X 91.8 MM
PACKAGE DIMENSIONS
• 65-INCH MODEL: 1050 MM X 1650 MM X 220 MM
• 75-INCH MODEL: 1170 MM X 1900 MM X 220 MM
• 86-INCH MODEL: 1300 MM X 2090 MM X 250 MM
NET WEIGHT
• 65-INCH MODEL: 35.5 KG
• 75-INCH MODEL: 47.8 KG
• 86-INCH MODEL: 63.0 KG
GROSS WEIGHT (INCLUDING THE PACKAGE)
• 65-INCH MODEL: 43.0 KG
• 75-INCH MODEL: 57.8 KG
• 86-INCH MODEL: 74.5 KG
(OPTIONAL) FLOOR STAND
PRODUCT DIMENSIONS 1525.0 MM X 1302.0 MM X 764.0 MM
PACKAGE DIMENSIONS 180 MM X 1390 MM X 845 MM
NET WEIGHT 19.5 KG
GROSS WEIGHT (INCLUDING THE PACKAGE) 24.8 KG
(OPTIONAL) WALL-MOUNTED BRACKET
PRODUCT DIMENSIONS 20 MM X 1100 MM X 200 MM
PACKAGE DIMENSIONS 55 MM X 1260 MM X 345 MM
NET WEIGHT 4.3 KG
GROSS WEIGHT (INCLUDING THE PACKAGE) 5.3 KG
(MANDATORY) STYLUS PEN
QUANTITY 2
WI-FI
WI-FI PROTOCOL 802.11 A/B/G/N/AC/AX
SUPPORTED FREQUENCY BAND
• 2.4 GHZ TO 2.4835 GHZ
• 5 GHZ TO 5.85 GHZ
MAXIMUM TRANSMIT POWER
• 2.4 GHZ TO 2.4835 GHZ: 20 DBM
• 5 GHZ TO 5.85 GHZ: 23 DBM
VOICE TRACKING
DISTANCE 3 M
INSTALLATION
INSTALLATION MODES FLOOR-MOUNTED, WALL-MOUNTED, OR WALL-RECESSED
