MODEL
PRIME X870-P WIFI
NEWS AND UPDATES
PLEASE REFER TO THE GLOBAL PRODUCT PAGE AT THE FOLLOWING LINK FOR THE LATEST NEWS AND SPECIFICATIONS.
HTTPS://WWW.ASUS.COM/MOTHERBOARDS-COMPONENTS/MOTHERBOARDS/PRIME/PRIME-X870-P-WIFI/TECHSPEC/
CPU
AMD SOCKET AM5 FOR AMD RYZEN 9000 AND 8000 AND 7000 SERIES DESKTOP PROCESSORS*
* REFER TO HTTPS://WWW.ASUS.COM/SUPPORT/DOWNLOAD-CENTER/ FOR CPU SUPPORT LIST.
CHIPSET
AMD X870 CHIPSET
MEMORIA
4 X DIMM SLOTS, MAX. 192GB, DDR5
SUPPORTS UP TO 8000+MT/S(OC) WITH RYZEN 9000 AND 8000 AND 7000 SERIES PROCESSORS
ECC AND NON-ECC, UN-BUFFERED DIMM*
DUAL CHANNEL MEMORY ARCHITECTURE
SUPPORTS AMD EXTENDED PROFILES FOR OVERCLOCKING (EXPO)
ASUS ENHANCED MEMORY PROFILE (AEMP)
* ADJUSTMENTS WILL BE MADE BASED ON THE SPECIFICATIONS OF MASS-PRODUCED MEMORY PRODUCTS AVAILABLE ON THE MARKET.
* SUPPORTED MEMORY TYPES, DATA RATE (SPEED), AND NUMBER OF DRAM MODULES VARY DEPENDING ON THE CPU AND MEMORY CONFIGURATION, FOR MORE INFORMATION PLEASE REFER TO CPU/MEMORY SUPPORT LIST UNDER THE SUPPORT TAB OF PRODUCT INFORMATION SITE OR VISIT HTTPS://WWW.ASUS.COM/SUPPORT/DOWNLOAD-CENTER/.
* NON-ECC, UN-BUFFERED DDR5 MEMORY SUPPORTS ON-DIE ECC FUNCTION.
GRÁFICOS
1 X HDMI PORT**
2 X USB4® (40GBPS) PORTS SUPPORT USB TYPE-C® DISPLAY OUTPUTS***
* GRAPHICS SPECIFICATIONS MAY VARY BETWEEN CPU TYPES. PLEASE REFER TO AMD CPU SPECIFICATIONS.
** SUPPORTS 4K@60HZ AS SPECIFIED IN HDMI 2.1.
*** SUPPORTS MAX. 4K@60HZ AS SPECIFIED IN DISPLAYPORT 1.4A.
**** VGA RESOLUTION SUPPORT DEPENDS ON PROCESSORS OR GRAPHIC CARDS RESOLUTION.
RANURAS DE EXPANSIÓN
AMD RYZEN 9000 AND 7000 SERIES DESKTOP PROCESSORS*
1 X PCIE 5.0 X16 SLOT (SUPPORTS X16 MODE)
AMD RYZEN 8000 SERIES DESKTOP PROCESSORS
1 X PCIE 4.0 X16 SLOT (SUPPORTS X8/X4 MODE)**
AMD X870 CHIPSET
3 X PCIE 4.0 X16 SLOTS (SUPPORT X1 MODE)***
* PLEASE CHECK THE PCIE BIFURCATION TABLE ON THE SUPPORT SITE (HTTPS://WWW.ASUS.COM/SUPPORT/FAQ/1037507/).
** SPECIFICATIONS VARY BY CPU TYPES.
*** PCIEX16(G4)_1 SHARES BANDWIDTH WITH M.2_2. PCIEX16(G4)_1 WILL BE DISABLED WHEN M.2_2 RUNS.
*** PCIEX16(G4)_2 AND PCIEX16(G4)_3 SHARE BANDWIDTH WITH M.2_3. PCIEX16(G4)_2 AND PCIEX16(G4)_3 WILL BE DISABLED WHEN M.2_3 RUNS.
- TO ENSURE COMPATIBILITY OF THE DEVICE INSTALLED, PLEASE REFER TO HTTPS://WWW.ASUS.COM/SUPPORT/DOWNLOAD-CENTER/ FOR THE LIST OF SUPPORTED PERIPHERALS.
ALMACENAMIENTO
SUPPORTS 4 X M.2 SLOTS AND 2 X SATA 6GB/S PORTS*
AMD RYZEN 9000 AND 7000 SERIES DESKTOP PROCESSORS
M.2_1 SLOT (KEY M), TYPE 2280 (SUPPORTS PCIE 5.0 X4 MODE)
AMD RYZEN 8000 SERIES DESKTOP PROCESSORS
M.2_1 SLOT (KEY M), TYPE 2280 (SUPPORTS PCIE 4.0 X4 MODE)
AMD X870 CHIPSET
M.2_2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)**
M.2_3 SLOT (KEY M), TYPE 2280 (SUPPORTS PCIE 4.0 X4 MODE)***
M.2_4 SLOT (KEY M), TYPE 2280 (SUPPORTS PCIE 3.0 X2 MODE)****
2 X SATA 6GB/S PORTS****
* AMD RAIDXPERT2 TECHNOLOGY SUPPORTS BOTH PCIE RAID 0/1/5/10 AND SATA RAID 0/1. RAID 5 FUNCTION IS ONLY SUPPORTED BY AMD RYZEN 9000 SERIES CPU.
** PCIEX16(G4)_1 SHARES BANDWIDTH WITH M.2_2. PCIEX16(G4)_1 WILL BE DISABLED WHEN M.2_2 RUNS.
*** PCIEX16(G4)_2 AND PCIEX16(G4)_3 SHARE BANDWIDTH WITH M.2_3. PCIEX16(G4)_2 AND PCIEX16(G4)_3 WILL BE DISABLED WHEN M.2_3 RUNS.
**** M.2_4 SHARES BANDWIDTH WITH SATA6G_1 AND SATA6G_2. M.2_4 WILL BE DISABLED WHEN SATA6G_1 OR SATA6G_2 RUNS.
ETHERNET
1 X REALTEK 2.5GB ETHERNET
ASUS LANGUARD
WIFI AND BLUETOOTH
WI-FI 7*
2X2 WI-FI 7 (802.11BE)
SUPPORTS 2.4/5/6GHZ FREQUENCY BAND**
SUPPORTS WI-FI 7 160MHZ BANDWIDTH, UP TO 2.9GBPS TRANSFER RATE.
BLUETOOTH® V5.4***
*WI-FI FEATURES MAY VARY DEPENDING ON THE OPERATING SYSTEM
FOR WINDOWS 11, WI-FI 7 WILL REQUIRE 24H2 OR LATER VERSION FOR FULL FUNCTIONS, WINDOWS 11 21H2/22H2/23H2 ONLY SUPPORT WI-FI 6E.
FOR WINDOWS 10, PLEASE NOTE THAT NO DRIVER IS AVAILABLE , PLEASE REFER TO THE WI-FI CHIPSET VENDORS WEBSITE FOR DETAILS.
** WI-FI 6GHZ FREQUENCY BAND AND BANDWIDTH REGULATORY MAY VARY BETWEEN COUNTRIES.
*** THE BLUETOOTH® VERSION MAY VARY, PLEASE REFER TO THE WI-FI MODULE MANUFACTURERS WEBSITE FOR THE LATEST SPECIFICATIONS.
USB
REAR USB (TOTAL 10 PORTS)
2 X USB4® (40GBPS) PORTS (2 X USB TYPE-C®)
1 X USB 10GBPS PORT (1 X TYPE-A)
3 X USB 5GBPS PORTS (3 X TYPE-A)
4 X USB 2.0 PORTS (4 X TYPE-A)
FRONT USB (TOTAL 7 PORTS)
1 X USB 10GBPS CONNECTOR (SUPPORTS USB TYPE-C®)
1 X USB 5GBPS HEADER SUPPORTS 2 ADDITIONAL USB 5GBPS PORTS
2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS
* USB TYPE-C® POWER DELIVERY OUTPUT: MAX. 5V/3A
AUDIO
REALTEK 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC*
- SUPPORTS: JACK-DETECTION, MULTI-STREAMING, FRONT PANEL JACK-RETASKING
- SUPPORTS UP TO 24-BIT/192 KHZ PLAYBACK
AUDIO FEATURES
- AUDIO SHIELDING
- PREMIUM AUDIO CAPACITORS
- DEDICATED AUDIO PCB LAYERS
* A CHASSIS WITH AN HD AUDIO MODULE IN THE FRONT PANEL IS REQUIRED TO SUPPORT 7.1 SURROUND SOUND AUDIO OUTPUT.
PUERTOS E/S TRASEROS
2 X USB4® (40GBPS) PORTS (2 X USB TYPE-C®)
1 X USB 10GBPS PORT (1 X TYPE-A)
3 X USB 5GBPS PORTS (3 X TYPE-A)
4 X USB 2.0 PORTS (4 X TYPE-A)
1 X HDMI PORT
1 X WI-FI MODULE
1 X REALTEK 2.5GB ETHERNET PORT
3 X AUDIO JACKS
1 X BIOS FLASHBACK BUTTON
PUERTOS E/S INTERNOS
FAN AND COOLING RELATED
1 X 4-PIN CPU FAN HEADER
1 X 4-PIN CPU OPT FAN HEADER
1 X 4-PIN AIO PUMP HEADER
4 X 4-PIN CHASSIS FAN HEADERS
POWER RELATED
1 X 24-PIN MAIN POWER CONNECTOR
2 X 8-PIN +12V CPU POWER CONNECTORS
STORAGE RELATED
4 X M.2 SLOTS (KEY M)
2 X SATA 6GB/S PORTS
USB
1 X USB 10GBPS CONNECTOR (SUPPORTS USB TYPE-C®)
1 X USB 5GBPS HEADER SUPPORTS 2 ADDITIONAL USB 5GBPS PORTS
2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS
MISCELLANEOUS
3 X ADDRESSABLE GEN 2 HEADERS
1 X CLEAR CMOS HEADER
1 X COM PORT HEADER
1 X FRONT PANEL AUDIO HEADER (F_AUDIO)
1 X S/PDIF OUT HEADER
1 X SPI TPM HEADER (14-1 PIN)
1 X 10-1 PIN SYSTEM PANEL HEADER
TECNOLOGÍAS ESPECIALES
ASUS 5X PROTECTION III
- DIGI+ VRM (- DIGITAL POWER DESIGN WITH DRMOS)
- LANGUARD
- OVERVOLTAGE PROTECTION
- SAFESLOT
- STAINLESS-STEEL BACK I/O
ASUS Q-DESIGN
- M.2 Q-LATCH
- PCIE SLOT Q-RELEASE
- Q-ANTENNA
- Q-DASHBOARD
- Q-DIMM
- Q-LED CORE
- Q-SLOT
ASUS THERMAL SOLUTION
- FLEXIBLE M.2 HEATSINK
- VRM HEATSINK DESIGN
ASUS EZ DIY
- BIOS FLASHBACK BUTTON
- BIOS FLASHBACK LED
- PROCOOL
- PRE-MOUNTED I/O SHIELD
- SAFESLOT
AURA SYNC
- ADDRESSABLE GEN 2 HEADERS
SOFTWARE
ASUS EXCLUSIVE SOFTWARE
ARMOURY CRATE
- AURA CREATOR
- AURA SYNC
- FAN XPERT 4 (WITH AI COOLING II)
- POWER SAVING
ASUS DRIVERHUB
ASUS GLIDEX
TURBOV CORE
ASUS CPU-Z
NORTON 360 DELUXE (60 DAYS FREE TRIAL)
WINRAR (40 DAYS FREE TRIAL)
UEFI BIOS
ASUS EZ DIY
- ASUS CRASHFREE BIOS 3
- ASUS EZ FLASH 3
- ASUS UEFI BIOS EZ MODE
- ASUS MYHOTKEY
BIOS
256 MB FLASH ROM, UEFI AMI BIOS
MANEJABILIDAD
WOL BY PME, PXE
ACCESORIOS
CABLES
2 X SATA 6GB/S CABLES
MISCELLANEOUS
1 X ASUS WIFI Q-ANTENNA
1 X M.2 RUBBER PACKAGE
2 X SCREW PACKAGES FOR M.2 SSD
DOCUMENTATION
1 X QUICK START GUIDE
SISTEMA OPERATIVO
WINDOWS 11
FACTOR DE FORMA
ATX FORM FACTOR
12 INCH X 9.6 INCH ( 30.5 CM X 24.4 CM )
