CAMARA
SENSOR DE IMAGEN
1/2.7 PROGRESSIVE SCAN CMOS
VELOCIDAD DEL OBTURADOR
1/3 TO 1/10000 S
OBTURADOR LENTO
YES
ILUMINACIÓN MÍNIMA
0.005 LUX; 0 LUX WITH IR/WHITE LIGHT
MECANISMO DÍA/NOCHE
IR CUT FILTER
SWITCH DÍA/NOCHE
UNIFIED/ SCHEDULED/ AUTO
LENS
TYPE
FIXED FOCAL LENS
FOCAL LENGTH
2.8/4 MM
APERTURE
F1.6
FOV
2.8 MM:
HORIZONTAL FOV: 111.4°, VERTICAL FOV: 58.8°, DIAGONAL FOV: 134°
4 MM:
HORIZONTAL FOV: 91.5°, VERTICAL FOV: 46.1°, DIAGONAL FOV: 109.6°
LENS MOUNT
M12*P 0.5
DORI DISTANCE
2.8 MM
DETECT: 85 M (278 FT)
OBSERVE: 35 M (116 FT)
RECOGNIZE: 17 M (56 FT)
IDENTIFY: 8 M (28 FT)
4 MM
DETECT: 107 M (350 FT)
OBSERVE: 44 M (146 FT)
RECOGNIZE: 21 M (70 FT)
IDENTIFY: 11 M (35 FT)
ANGLE ADJUSTMENT (MANUAL)
RANGE
PAN: 0° TO 360°, TILT: 0° TO 85°, ROTATION: 0° TO 360°
ILLUMINATOR
IR LED
QUANTITY: 4
RANGE: 30M
WAVELENGTH: 850NM
WHITE LED
QUANTITY: 4
RANGE: 30M
ILLUMINATOR ON/OFF CONTROL
AUTO/SCHEDULED/ALWAYS ON/ALWAYS OFF
VIDEO
MAX. RESOLUTION
3840 X 2160
MAIN STREAM
FRAME RATE AND #65306;
50HZ: 1FPS, 5FPS, 10FPS, 15FPS, 20FPS, 25FPS
60HZ: 1FPS, 5FPS, 10FPS, 15FPS, 20FPS, 25FPS
RESOLUTION:
3840X2160, 2560X1440, 2304X1296, 2048X1280, 1920X1080,
1280X720
NOTE:
IF THE IMAGE ROTATION IS SET TO 90° OR 270°, THE FRAME RATE ONLY SUPPORTS UP TO 20FPS.
IF 120DB IS TURNED ON, THE FRAME RATE CAN ONLY SUPPORT UP TO 20FPS.
SUB-STREAM
FRAME RATE AND #65306;
50HZ: 1FPS, 5FPS, 10FPS, 15FPS, 20FPS, 25FPS
60HZ: 1FPS, 5FPS, 10FPS, 15FPS, 20FPS, 25FPS
RESOLUTION:
704X576,640X480, 352X288, 320X240
NOTE:
IF THE IMAGE ROTATION IS SET TO 90° OR 270°, THE FRAME RATE ONLY SUPPORTS UP TO 20FPS.
IF 120DB IS TURNED ON, THE FRAME RATE CAN ONLY SUPPORT UP TO 20FPS.
BIT RATE CONTROL
CBR, VBR
COMPRESIÓN DE VIDEO
MAIN STREAM: H.265+/H.265/H.264+/H.264
SUB-STREAM: H.265/H.264
H.264 TYPE
HIGH PROFILE
H.264+
MAIN STREAM SUPPORTED
H.265 TYPE
MAIN PROFILE*
H.265+
MAIN STREAM SUPPORTED*
VIDEO BIT RATE
MAIN STREAM: 256 KBPS TO 6 MBPS
SUB-STREAM: 64 KBPS TO 512 KBPS
IMAGE SETTINGS
MIRROR
BRIGHTNESS
CONTRAST
SATURATION
SHARPNESS
EXPOSURE
WDR
WHITE BALANCE
PREVENT OVEREXPOSURE TO INFRARED LIGHT
HLC ADJUSTABLE BY CLIENT SOFTWARE
IMAGE ENHANCEMENT
BLC/3D DNR/HLC/SMARTIR
WIDE DYNAMIC RANGE
120 DB
SNR
AND #8805; 52 DB
IMAGE PARAMETERS SWITCH
YES
PRIVACY MASK
UP TO 4 MASKS
ROI
1 REGION
OSD SETTING
YES
AUDIO
COMUNICACIÓN DE AUDIO
TWO-WAY AUDIO
AUDIO INPUT
YES
AUDIO OUTPUT
YES
AUDIO COMPRESSION
YES
AUDIO SAMPLING RATE
8KHZ
ENVIRONMENT NOISE FILTERING
YES
AUDIO BIT RATE
64 KBPS(G.711 ALAW)
NETWORK
PROTOCOLO
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPNP UDP, SSL/TLS
ONVIF
YES
API
OPEN NETWORK VIDEO INTERFACE (PROFILE S)
SIMULTANEOUS LIVE VIEW
3 MAIN STREAMS AND 3 SUB-STREAMS
CLIENT
VIGI APP, VIGI SECURITY MANAGER, WEB UI, VIGI VMS
WEB BROWSER
GOOGLE CHROME® 57 AND ABOVE
FIREFOX® 52 AND ABOVE
SAFARI® 11 AND ABOVE
MICROSOFT® EDGE 91 AND ABOVE
CLOUD
YES
SEGURIDAD
PASSWORD PROTECTION, HTTPS ENCRYPTION, IP ADDRESS FILTER, DIGEST AUTHENTICATION
ALARMA Y GESTIÓN DE EVENTOS
SMART EVENT
HUMAN AND VEHICLE CLASSIFICATION
INTRUSION DETECTION
LINE-CROSSING DETECTION
REGION ENTERING DETECTION
REGION EXITING DETECTION
OBJECT ABANDONED DETECTION
OBJECT REMOVAL DETECTION
LOITERING DETECTION
SMART FRAME
PEOPLE DETECTION
VEHICLE DETECTION
BASIC EVENT
MOTION DETECTION
VIDEO TAMPERING DETECTION
EXCEPTION ( ILLEGAL LOGIN)
SCENE CHANGE DETECTION
ALARM LINKAGE
MEMORY CARD VIDEO RECORDING
MESSAGE PUSH
AUDIBLE WARNING
WHITE LIGHT FLASHING
LINKAGE METHOD
N/A
OUTPUT NOTIFICATION
MESSAGE PUSH
INTERFACES
NETWORK INTERFACE
1 RJ45 10/100M SELF-ADAPTIVE ETHERNET PORT, POE
ALARM
N/A
RESET BUTTON
YES
POWER
DC POWER PORT
ON-BOARD STORAGE
BUILT-IN MEMORY CARD SLOT, SUPPORT MICROSD CARD, UP TO 256 GB**
BUILT-IN MICROPHONE
YES; RECORDS ANYTHING GOING ON WITHIN A 15-FT RADIUS OF THE CAMERA
BUILT-IN SPEAKER
YES
AUDIO
N/A
GENERAL
TEMPERATURA DE FUNCIONAMIENTO
-3060 °C
STORAGE TEMPERATURE
-4060 °C
HUMEDAD DE FUNCIONAMIENTO
95% OR LESS (NON-CONDENSING)
STORAGE HUMIDITY
95% OR LESS (NON-CONDENSING)
CONTENIDOS DEL PAQUETE
VIGI NETWORK CAMERA
QUICK START GUIDE
WATERPROOF CABLE ATTACHMENTS
MOUNTING ACCESSORIES
MATERIAL
METAL
NET WEIGHT
0.48 KG
POWER SUPPLY
12V DC ± 5%, MAX. 11.5 W, 5.5 MM COAXIAL POWER PLUG
POE: 802.3AF/AT, CLASS 0, MAX. 12.5 W
PROTECTION
IP67
PRODUCT DIMENSIONS (L X W X H)
111 × 111 × 83.7 MM
CERTIFICACIONES
CE, NTRA, VCCI, KC, BSMI, FCC, IC
